Brand:
SUNTREE OR OEM SERVICE
Item NO.:
SUNTREE HV BATTE
Payment:
30% deposit + 70% balance before shipping
Product Origin:
CHINA
Color:
WHITE
Shipping Port:
shenzhen, shanghai
Type:
LiFePO4 Battery
Max Power :
25KWH
Maintenance Type:
Free
Cycle Life:
20Years
Certification:
IEC, TUV, UL,CE
Lead Time:
7 Days
Warranty:
15 Years
360V 10KWH 15KWH 20KWH 25KWH Storage LiFePO4 Lithium Batteries 50AH for Deye 50KW Inverter Hybrid
Lithium Ion Battery Info
*204V-512V wide voltage
*10KWH-25KWH wide Capacity, 50AH battery cells low capacity option
*Easy installation with modular and stacked design
*Remote firmware upgrade
*IEC, CE, CEC, UN38.3, UL1973 Certificates
*Compatible with all brands Hybrid Inverters
SUNTREE Lithium Ion Battery Specification
Model |
10KWH |
15KWH |
20KWH |
25KWH |
|
Nominal Voltage |
204.8V |
307.2V |
409.6V |
512V |
|
Cell Model |
3.2V 50AH | |||
|
Cell Capacity |
50AH | |||
|
Rated Energy |
5.12KWH | |||
|
Usable Energy |
4.6KWH | |||
|
Max Charge Current |
25A | |||
|
Max Discharge Current |
50A | |||
|
Volatage Range |
180-228V |
270-340V |
350-450V |
440-560V |
|
Communication |
RS232-PC,RS485-Inverter,Canbus-Inverter | |||
|
Cycle Life |
＞ 6000 Cycles | |||
|
Design Life |
20 + Years | |||
|
Approx Weight |
130KG |
180KG |
230KG |
280KG |
|
Demension (W*D*H mm) |
630*185*950 |
630*185*1290 |
630*185*1640 |
630*185*1980 |
|
IP Grade |
IP 65 | |||
|
Protection |
BMS, Breaker | |||
|
Safety |
UN38.3, MSDS, IEC62619, UL1973, CE, UL2054 | |||
SUNTREE Battery Projects
As a professional lithium battery manufacturer, our lithium battery not only covers 12.8V, 25.6V, 48V, 51.2V conventional low-voltage products, but also provides high-voltage energy storage lithium battery solutions from 96V to 1000V according to customer requirements.
Compared with ordinary lead-acid batteries,our LiFePO4 batteries have more advantages.
1. With the same capacity, the weight is lighter
2. Longer life, generally more than 20 years
3. Faster charging speed and lower self-discharge rate.
4. Built-in BMS, higher security.
Our lithium battery cells come from first-line manufacturers, including CATL, BYD, EVE and other brands.
All batteries are of A+ quality to ensure that the product quality can meet the requirements of customers.
At the same time, our lithium batteries comply with CE, IEC, ISO, UL, MSDS, UN38.3 and other product certifications to meet the local sales and use requirements of customers in multiple markets.
At present, our lithium battery products have been exported to more than 100 countries and regions, and we provide quality assurance and after-sales service for all products.
According to the product status feedback from customers, remote upgrade control or free replacement of BMS motherboard accessories.
